CPU

LGA775

Support Intel® Core™ 2 Duo/Pentium® D/Pentium® 4 Processor

Supports 1066/800/533MHz FSB

Chipset

Northbridge Chipset: VIA P4M900

Southbridge Chipset: VIA 8237S

Realtek 8201 (10/100 PHY)

VIA 1708A HD audio Codec

Memória

2 DIMM memory slots (supports up to 4GB memory) (Note 1)

Supports 1.8V DDR DIMM

Supports DDR2 667/533/400 DIMM (Note 2)

(Note 1) Use of a 1066/ 800 MHz FSB CPU is required if you wish to install DDR2 667 MHz memory.

(Note 2) Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

Slots de Expansão

1 x PCI Express x16 slot

1 x PCI Express x1 slot

2 x PCI slots

Conectores Internos I/O

1 X 24-pin ATX power connector

1 X 4-pin ATX 12V power connector

1 X Floppy connector

2 X IDE connectors

2 X SATA 3Gb/s connectors

1 X CPU fan connector

1 X System fan connector

1 X Front panel connector

1 X Front audio connector

1 X HDA_SUR connector

1 X CD IN connector

1 X SPDIF IN/OUT connector

2 X USB 2.0/1.1 connectors for additional 4 USB 2.0/ 1.1 ports by cable

1 X COMB connector

1 X Chassis intrusion connector

1 X Power LED connector

Conectores Painel Traseiro

1 X PS/2 Keyboard port

1 X PS/2 Mouse port

1 X Parallel port

1 X Serial port

1 X D-Sub port

4 X USB 2.0/1.1 ports

1 X RJ45 ports

3 X Audio jacks (Line-out / Line-in / MIC in)

Form Factor

Micro ATX

24.4cm x 23.3cm

Observação

Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.

Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.

* Todos os materiais disponíveis são para simples referência. A GIGABYTE reserva o direito de modificar ou revisar o conteúdo a qualquer momento sem aviso prévio.

* Todas as marcas e logotipos são de propriedade de suas respectivas proprietárias.

* Devido a arquitetura padrão PC, uma quantia de memória é reservada para uso do sistema, portanto o tamanho da memória é menor do que a quantia exibida
